165,000.00
| Others: | |
| All the functions are PLC controlled. | Very High fill Accuracy of ± 0.5 %. |
| Availability | In Stock |
| Brand | HMPL |
| Digitally controlled settings. | Single phase low voltage requirement. |
| Driven Type | Electric |
| Easy to adjust different filling volume. | There is no direct contact of liquid material with any mechanical component because the liquid passing through the Pharma grade silicon tubes only. |
| Filling Capacity | 50ml onwards |
| Machine Type | Semi-Automatic |
| Model Name/Number | SPRF - 13.5 |
| No change parts required for different filling volumes / bottles - Except tube dia. | Flow of liquid can be controlled by PLC. |
| Output | 500 ml 15 - 20 bpm (Water)/Minute |
| Power Consumption | 0.20 kW |
| Power Supply | Single Phase / 230 V AC / 50 Hz (Stabilized) |
| Pump Capacity | 13.5 ltr/min max |
| Size/Dimension | 250 x 550 x 400 Inch |
| Suitable For | 50ml - 1000ml |
| The contact parts are made of SS 316L such as Nozzles. | Rigid vibration free construction for trouble free performance. |
| The unit is made compact & versatile as per GMP norms. | The whole structure is made of SS 304 matt finish. |
| Unique feature of "PRIME" is useful to remove air which is inside the filling line very quickly to minimize the production loss also the prime feature is useful to clean filling line with special appl | Machine has electronic components such as Stepper motor, PLC, Feather touch key board and sensor etc, thus avoiding mechanical parts such as Piston, Syringe, Teflon piston rod and pneumatic etc. |
| Use of pharma grade / food grade silicon tube for the flow of liquid to facilitate high temperature liquid (up to 120°C). | Unique Bottle & Nozzle holding device for various height adjustments without any change parts. |
| User friendly and high scalability. | No Bottle No Filling. |
| Weight | 20 Kg |
| Working Height | Table Top |
₹
165,000.00
| General Details: | |
| Automation Grade | Automatic |
| Others: | |
| All the functions are PLC controlled. | Very High fill Accuracy of ± 0.5 %. |
| Availability | In Stock |
| Brand | HMPL |
| Country of Origin | Made in India |
| Digitally controlled settings. | Single phase low voltage requirement. |
| Driven Type | Electric |
| Easy to adjust different filling volume. | There is no direct contact of liquid material with any mechanical component because the liquid passing through the Pharma grade silicon tubes only. |
| Filling Capacity | 2ml onwards |
| Machine Type | Semi-Automatic |
| Model Name/Number | HMPL - SPRF - 3.5 |
| No change parts required for different filling volumes / bottles - Except tube dia. | Flow of liquid can be controlled by PLC. |
| Output | 5 ml 30 - 35 bpm (Water)/Minute,100 ml 10 - 15 bpm (Water)/Minute |
| Power Consumption | 0.20 kW |
| Power Supply | Single Phase / 230 V AC / 50 Hz (Stabilized) |
| Pump Capacity | 3.5 ltr/min max |
| Size/Dimension | 200 x 450 x 300 Inch |
| Suitable For | 2ml - 50ml,10ml - 200ml |
| The contact parts are made of SS 316L such as Nozzles. | Rigid vibration free construction for trouble free performance. |
| The unit is made compact & versatile as per GMP norms. | The whole structure is made of SS 304 matt finish. |
| Unique feature of "PRIME" is useful to remove air which is inside the filling line very quickly to minimize the production loss also the prime feature is useful to clean filling line with special appl | Machine has electronic components such as Stepper motor, PLC, Feather touch key board and sensor etc, thus avoiding mechanical parts such as Piston, Syringe, Teflon piston rod and pneumatic etc. |
| Use of pharma grade / food grade silicon tube for the flow of liquid to facilitate high temperature liquid (up to 120°C). | Unique Bottle & Nozzle holding device for various height adjustments without any change parts. |
| User friendly and high scalability. | No Bottle No Filling. |
| Weight | 6.0 Kg |
| Working Height | Table Top |
