850,000.00
| General Details: | |
| Phase | Single Phase |
| Model | HMPL–SSA |
| Automation Grade | Automatic |
| Usage/Application | Labeling |
| Speed | 80 to 120 BPM |
| Others: | |
| Availability | In Stock |
| Bottle Sample | Glass/HDPE/Plastic Bottles |
| Bottle Size (Ø) | 30mm Ø to 120 mm Ø |
| Bottle Type | Round |
| Brand | HMPL |
| Country of Origin | Made in India |
| Dimensions | 3050 mm (L)x 1200mm (W)x 2000mm(H) Approx. |
| Frequency | 50 Hz |
| Net Weight | 550 Kg Approx. |
| Output Speed | 120 to 150 Bottles/Minute (Speed depends on cut length) |
| Power Consumption | 6.5 KW |
| Power Supply | 3 Phase + Neutral + Earthing / 440V AC / 50Hz |
| Sleeve Length | 30mm to 100mm |
| Sleeve Material | OPS PVC with 40 to 50 micron 55% shrink ratio |
| Sleeve Width | 40mm to 170mm |
| Voltage | 230 V AC |
| Working Height | 850 ± 50 mm Adjustable |
